OPERATOR’S MANUAL with Maintenance Information
Maintenance
55
Display
for
Platform
Display for Ground
Description
Repair
33
PCU LF outrigger button
fault
Platform Left Front Outrigger
Enable Switch ON at power-up
up
Check the switch,
replace the platform
34
PCU RF outrigger button
fault
Platform Right Front Outrigger
Enable Switch ON at power-up
Check the switch,
replace the platform
35
PCU LR outrigger button
fault
Platform Left Rear Outrigger
Enable Switch ON at power- up
Check the switch,
replace the platform
36
PCU RR outrigger button
fault
Platform Right Rear Outrigger
Enable Switch ON at power-up
Check the switch,
replace the platform
37
PCU auto outrigger button
fault
Platform Outrigger Auto Level
Enable Switch ON at power-up
Check the switch,
replace the platform
41
High Limit Switch Fault
High Limit Switch Fault
Check the switch,
check the wiring
42
9m limit switch fault
9M Limit Switch Fault
Check the switch,
check the wiring
43
Outrigger not extended
Outrigger Not Extended Fault
Extend Outrigger or lift
down the platform.
44
Float limit switch fault
Float Limit Switch Fault
Check the switch,
check the wiring
45
Float En valve Fault
Float Enable valve Fault
check the wiring,
replace the valve
46
Float Unload valve Fault
Float Unload valve Fault
check the wiring,
replace the valve
47
Float Lock valve Fault
Float Lock valve Fault
check the wiring,
replace the valve
48
Left float valve fault
Left float valve fault
check the wiring,
replace the valve
49
Right float valve fault
Right float valve fault
check the wiring,
replace the valve
53
Proportional valve fault
Proportional valve fault
check the wiring,
replace the valve
54
UP valve fault
Power FET, channel DOWN
fails
check the wiring,
replace the valve
55
Down valve fault
Power FET, channel RT fails
check the wiring,
replace the valve
56
Steer right valve fault
Power FET, channel LT fails
check the wiring,
replace the valve
57
Steer left valve fault
Power FET, channel LT fails
check the wiring,
replace the valve
58
Brake valve fault
Brake valve fault
check the wiring,
replace the valve
