DINGLI JCPT2212DC - Legend

OPERATOR’S MANUAL with Maintenance Information
Legend
8
Legend
1 Platform entry gate
9 Batteries, Hydraulic tanks (behind cover)
2 Lanyard anchorage point
10 Front wheel
3 Platform guard rails
11 Batteries, Hydraulic manifold (behind
cover)
4 Main Platform
12 Lift Cylinder
5 Platform extensions
13 Ground controls
6 Platform controls
14 Rear wheel
7 Manual storage containers
15 Outrigger
8 Scissor Arms
16 Entry ladder
4
7
8
16
13
11
12
10
9
1
2
3
5
6
14
15
