OPERATOR’S MANUAL with Maintenance Information
Control Panel
16
Ground Control Panel
1 Display
Diagnostic readout
2 Indoor/outdoor button
Light on indicates to select the outdoor
mode, and the diagnostic will display the
outdoor. In outdoor mode, the machine
cannot lift until all for outriggers extend.
Light off indicates to select the indoor
mode. In indoor mode, the machine lift
regardless of whether the four outriggers
extend or not.
When outdoors, work may only be
done in support mode! FAILURE TO DO SO
COULD RESULT IN DEATH OR SERIOUS
INJURY.
3 Overload indicator light
Light on indicates when overloaded.
4 Standby
5 Standby
6 Battery gauge & hour meter
Battery gauge & hour meter is used to
Display the Working Hours and Battery
level.
7 Key switch
Turn the key switch to the platform
position and the platform controls will
operate.
Turn the key switch to the off position and
the machine will be off. Turn the key
switch to the base position and the ground
controls will operate.
8 Red Emergency Stop button
Push in the red Emergency Stop button to
the off position to stop all functions. Turn
the red Emergency Stop button clockwise
to the on position to operate the machine.
9 Platform down button
Press this button and the platform will
lower
10 Lift function enable button
Press this button to activate the lift
function.
11 Emergency lowering down button
Press this button and the platform will
lower
12 Platform up button
Press this button and the platform will lift.
13 Emergency lowering down enable button
Press this button to activate the
Emergency down function.
