Dingo K9-4 Operation & Maintenance Manual
27
Remote Control Bank
Part Numbers
Item Qty Dingo Part No Description
1 1 330-003-051 Remote Bank
2 2 316-375-502 Hydraulic Fitting (CR2-0609)
3 2 316-377-501 Hydraulic Fitting (CR2-0614)
4 1 312-470-000 Blanking Plug 1/2”
5 4 312-370-000 Blanking Plug 3/8”
6 1 315-376-500 Hydraulic Fitting (CP56-0612)
7 2 315-477-500 Hydraulic Fitting (CP56-0814)
8 1 315-377-500 Hydraulic Fitting (CP56-0614)
9 1 K94482 Remote Handle Bent
10 1 K94483 Remote Handle Z Bend
11 1 K94481 Remote Handle Straight. Short
12 1 318-111-100 Male Quick Release Flush Face (2FFI14GASM)
13 1 318-112-100 Female Quick Release Flush Face (2FFIGASF)
14 2 316-372-700 Hydraulic Fitting (CR1-0604)
15 3 111-311-060 Hex Bolt M8 x 60
16 3 122-131-000 Nyloc Nut M8
17 1 K94414 Pipe - Pump Selector To Remote Bank (AP)
18 1 K94413 Pipe - Main Bank To Dump (CD)
19 1 317-769-575 Hydraulic Fitting (C64-141714)
20 1 K94428 Pipe - Remote Bank to 3/8” Aux (A4)
21 1 K94427 Pipe - Remote Bank to 3/8” Aux (A3)
22 1 K94426 Pipe - Remote Bank To 1/2” Aux (A2)
23 1 K94425 Pipe - Remote Bank To 1/2” Aux (A1)
24 2 316-555-500 Hydraulic Fitting (C2-0909)
25 2 330-000-018 15 mm Hose Clamp Block
26 1 330-000-016 15mm Hose Guide Plate
27 1 K94411 Pipe - Flow Control To Remote Bank (EX)
28 1 K94450 1/2” Hyd-Hose 1/2” Female Quick Release To Front Fitting (1150mm)
29 1 K94451 1/2” Hyd-Hose 1/2” Male Quick Release To Rear Fitting (1180mm)
30 1 K94452 1/4” Hyd-Hose 3/8” Female Quick Release To Front Fitting (1105mm)
31 1 K94453 1/4” Hyd-Hose 3/8” Male Quick Release To Rear Fitting (1130mm)
