Dingo K9-4 Operation & Maintenance Manual

K9-4

Qty Drawing Pipe No Description Kohl TNE TNV Perk

1 K94-411 EX Flow control to remote bank a a a a

1 K94-412 FP hi/low valve to ow control a a a a

1 K94-413 CD Main bank to dump pipe a a a a

1 K94-414 AP Hi/Low To Aux Bank a a a a

1 K94-415 C1 R Rear wheel motor a a a a

1 K94-416 C2 R Front Wheel Motor a a a a

1 K94-417 . L Rear Wheel Motor No Relief (Obsolete Use K94436) r r r r

1 K94-418 . L Front Wheel Motor No Relief (Obsolete Use K94437) r r r r

2 K94-419 C5 Front to rear wheel motor pipe aa aa aa aa

1 K94-420 . Diesel Dump Pipe (Obsolete was original DD pipe) r r r r

1 K94-421 DV1 Diesel Wheel motor 1 c-bank to o/c valve r a r a

1 K94-422 DV2 Diesel Wheel motor 2 c-bank to o/c valve r a r a

1 K94-423 DV3 Diesel Wheel motor 3 c-bank to o/c valve r a r a

1 K94-424 DV4 Diesel Wheel motor 4 c-bank to o/c valve r a r a

1 K94-425 AI Remote to Large Aux 1 a a a a

1 K94-426 A2 Remote to Large Aux 2 a

a a a

1 K94-427 A3 Remote to Small Aux 1 a a a a

1 K94-428 A4 Remote to Small Aux 2 a a a a

1 K94-429 T1 Control Bank to Crowd Hose 1 a a a a

1 K94-430 T2 Control Bank to Crowd Hose 2 a a a a

1 K94-431 DD Diesel Dump Pipe External Filter (Current) r a r r

1 K94-436 C3 L Rear Wheel Motor with Relief a a a a

1 K94-437 C4 L Front Wheel Motor with Relief a a a a

1 K94-438 DDA Diesel Dump Pipe Internal Filter (Current) r r a a

1 K94-476 F1 Filter to Tank Dump a a r r

1 K94-492 DV1-2 Diesel Wheel motor 1 c-bank to o/c valve 40mm Rear r r a r

1 K94-493 DV2-2 Diesel Wheel motor 2 c-bank to o/c valve 40mm Rear r r a r

1 K94-494 DV3-2 Diesel Wheel motor 3 c-bank to o/c valve 40mm Rear r r a r

1 K94-495 DV4-2 Diesel Wheel motor 4 c-bank to o/c valve 40mm Rear r r a r

1 K94-477 PV1 Petrol Wheel motor 1 c-bank to o/c valve a r r r

1 K94-478 PV2 Petrol Wheel motor 2 c-bank to o/c valve a r r r

1 K94-479 PV3 Petrol Wheel motor 3 c-bank to o/c valve a r r r

1 K94-480 PV4

Petrol Wheel motor 4 c-bank to o/c valve a r r r

1 K94-432 PD Petrol Dump Pipe External Filter (Current) a r r r

1 K94-439 PDA Petrol Dump Pipe Internal Filter (Not Yet Existing) a r r r

Hydraulic Pipes On K9-4
