DFW series indicators DFW_03_12.07_EN_U
31
the indicator should turn off: enter a number between 1 and 255 (using the MODE key to select the digit to be modified
and ZERO/TARE to decrease/increase it) and confirm with ENTER/PRINT.
- Press many times the C key until the display shows “SAVE?”.
- Press ENTER/PRINT to confirm the changes made or another key for not saving.
NOTE: If the indicator is in master mode, the "autoff" parameter only works when the display shows "eco n"
9.5 LOW BATTERY WARNING
DFW model.
The indicator is able to recognize whether it is powered from the mains or through a battery.
DFWL, DFWLB, DFWLI, DFWLIB, DFWLID, DFWPM, DFWLKR, DFWLKRF and DFWLAP models.
One should set the supply mode setting the step SEtuP >> ALiM.
If the indicator has the LCD display the charge level is shown in the weighing phase through the battery symbol:
-
:
battery is charged.
- : battery is partially charged.
- : battery is discharged: connect the indicator to the mains in order to recharge the battery (if supplied) or replace it.
Furthermore, for a few seconds the "Low.bat " message appears on the display (minimum level voltage).
When recharging the battery (if supplied), the indicator shows the recharging phase below:
RECHARGING PHASE: …
RECHARGE IS COMPLETED:
NOTES:
- While recharging, the instrument can be used as usual.
- The instrument automatically turns off when the voltage goes below the minimum level.
- It’’s possible to view the recharge percentile of the battery by pressing the ZERO key upon start-up (see the section
“POWER SUPPLY AND START-UP”).
9.6 "TILT" DEVICE
The TILT is a device which inhibits the indicator’s weighing system and starts working when the instrument’s inclination is
greater than 2% for the pallet truck application or 5% for application on lift trucks.
The “tilt” message the weight value are alternately shown on the display.
The activation of the tilt alarm has a delay of about three seconds from the detection of the exceeding inclination.
See the electrical connection scheme (TECH.MAN.REF.) for the connection of the device.
9.7 MULTI RANGE FUNCTIONING (for legal for trade approved instruments)
The multi range functioning allows to subdivide the scale capacity in two or three ranges, each which is up to 3000
divisions, improving in this way the first range division in the dual range and the first two ranges in the triple range.
For example, with a 30 kg cell platform it is possible to approve the weighing system with:
- A single range: 6 kg capacity and 2 g division (3000 div.).
- Dual range: 6 / 3 kg capacity and 2/1 g division (3000 + 3000 div.).
- Triple range: 15 / 6 / 3 kg capacity and 5/2/1 g division (3000 + 3000 + 3000 div.).
NOTES:
- For the approval of the weighing system in dual and triple range the cell must have better technical features in comparison
to the cell used for the approval in a single range.
The multirange functioning is shown by the turning on of the relative LED which identifies the range in which one is
operating; by passing to the second range, the second range division is enabled; by passing to the third range, the third
range division is enabled. At this point the first range division is restored only by passing by the gross zero of the scale.
- The selection of the range number with multirange functioning is made during the indicator’s calibration
(TECH.MAN.REF.).
