3.3 Printer Configuration
This printer permits the configuration of default parameters. The printer’s configurable paramenters are:
• Baud Rate: 38400, 19200, 9600, 4800, 2400,1200, 600.
• Data length: 7, 8 bits/car.
• Parity: None, Even or Odd.
• Handshaking: XON/XOFF o Hardware.
• Autofeed: CR disable o CR enabled.
• Columns: 24 col , 40 col. e 42 col.
• Print Mode: Normal or Reverse.
• Char mode: Normal , Double Width (2 x Width), Double height (2 x Height),
Expanded.
• Alignment: Disabled or Enabled.
• Densità di stampa: -2, -1, 0, +1, +2.
General note: The settings made are stored in nonvolatile memory and are loaded automatically. During power-up, if the
FEED key is held down, the printer enters the autotest routine and prints out the setup report. The printer will remain in
standby in Hexadecimal dump mode (see section 1.7) until another key is pressed or characters are received through the
printer communication port. When the FEED key is pressed, the printer enters parameter configuration. Each time the
FEED Key is pressed, the parameter will change and the current value will be printed out.
Once the desired value has been attained, hold the FEED key down for at least a second to pass to the next parameter,
and so on. Printing out of new printer set up report indicates that set up is complete.
3.3.1 CONNECTION SET-UP WITH DFW-DFWK-CPW03-TRS03 3590XX/0X
*PRINTER SETUP *
HEAD TEMP [° C] = 27.5
HEAD VOLT [ V] = 4.6
Baud Rate :9600 bps
Data Length:8 Bits/ chr
Parity: None
Hanshaking:RTS/CTS
Autofeed: CR Enabled
Columns: 24 col.
Print Mode: Reverse
Chars Mode: Normal
Alignment: Disabled
Print Dens. + 1
