Parts List
X20 Motor Cover &Cart
NO.
Series NO.
Description
Qty
NO.
Series NO.
Description
Qty
1
X20701
Screw
4
6
X20606
Screw
3
2
X20702
Frame
1
7
X20607
Motor cover
1
3
X20703
Suction/drain cup
1
8
X20608
Front cover
1
4
X20704
Screw
1
9
X20609
Screw
2
5
X20605
Power wire
1
