Parts List
X24 Motor Assembly
X24 Electric Pressure Control Board
No.
Serial No.
Description
Qty
1
X24301
Stator
1
2
X24302
Rotor
1
3
X24303
Baffle
1
4
X24304
Fan
2
5
X24305
Washer
1
6
X24506
Long Screw
1
