Parts List
X24 Cart&Motor Cover Assembly
NO.
Series NO.
Description
Qty
NO.
Series NO.
Description
Qty
1
x24701
Screw
4
6
x24606
Screw
3
2
x24702
Frame
1
7
x24607
Motor cover
1
3
x24703
Suction/drain cup
1
8
x24608
Front cover
1
4
x24704
Screw
1
9
x24609
Screw
2
5
x24605
Power wire
1
