INSTALLATION
Installation
Installing Electricity
3. 220V 1 Phase Circuit Breaker
• Electrical specification
- 220~240V 1PH (Plus GND)
- Use circuit breaker with proper ratings
- cable : Above 400V, 3 Wires
: Below 7kw (Wire Diameter : Above 4￠)
Model Output Ampere Voltage
DIBK226(S)-E 5.2kw 24A 220~240V 1PH
DIBK235(S)-E 6.6kw 30A 220~240V 1PH
DIBK261(S)-E 5.9kw 27A 220~240V 1PH
DIBK218(S)-E 4kw 18A 220~240V 1PH
DIHG900-E 6.6kw 30A 220~240V 1PH
DIHG450-E 3.3kw 16A 220~240V 1PH
★ Caution : When you install DIHG450-E Models, each unit
must have be installed on a dedicated circuit.
