Installation
DIBK-E Series
Holes
580mm
280mm
26
INSTALLATION
2. Space of 10cm and holes to front of product is needed for
ventilation.
4. Hole Size of Products
3. When products have been built-in, reinforcement stand is required
in order to bear weight of products.
1. Match size of hole with size of product as possible.
Size of Product
Hole Size
For sufficient ventilation
the holes as right
picture are required.
5. Hole Size of Control Panel
Hole Size
600mm
300mm
220mm
Front Part Holes of
case for built-in
225mm
242mm
100mm
102mm
