Directed Audio A1004 - Specifications

2222
© 2004 Directed Electronics, Inc
SPECIFICATIONS
AA880022,, AA11000044,, aanndd DD22220055
Conversion Efficiency >66% @ 4 ohms
Frequency Response 20-20,000 Hz
Signal-to-Noise Ratio >98 dBA
Separation 65 dB @ 1 kHz
Damping Factor >150, >50 (D2205 sub-channel)
Crossover Type/Range 2-way Butterworth/50 to 500 Hz
Crossover Slope 12 dB/octave
Bass Equalization 0 to +8 dB
Subsonic Filter Variable
RCA Input/Output Jacks 2-channel in/2-channel paralleled full-range out
Input Impedance 20K ohms
Input Sensitivity Variable from 250 mV to 8 volts
Supply Voltage 10 to 16 VDC
Fusing
30Ax2 (A802)
40Ax2 (A1004)
40Ax3 (D2205)
Minimum Cable Requirements
(AWG)
#8
Dimensions varies
Port Output (Optional
Fan)/LED (Optional)
12V @<200mA
