Dirt Devil BLADE 2 - Using the Stick Vac; Maintaining the Stick Vac; Removing and Refitting the Dirt Container

14
much charge is remaining. When less than 20%
charge is remaining the bottom light will ash
red indicating the battery is running low and
charging is required (Fig.
7
/3).
Using the stick vac
1. Place your foot on the powered head
(Fig.
8
/1) and pull the handle backwards to
recline (Fig.
8
/2).
2. To switch the stick vac on, press the ON/OFF
button located on the handle. (Fig.
9
/1) The On/
O button and battery level indicator lights on
the handle will illuminate (Fig.
7
/2).
3. To increase suction for particularly dirty areas
that require additional cleaning boost mode can
be activated (Fig.
9
/3).
4. To switch the brushbar on, press the brushbar
ON/OFF button (Fig.
9
/2). The light on the
powered head and the brushbar ON/OFF light
will illuminate when the brushbar is on and the
brushbar will constantly spin. Press the brushbar
ON/OFF button again to turn the brushbar o.
5. All of the accessories, including the powered
head can be attached directly onto the handheld
(Fig.
10
) or the reach wand. The crevice tool and
dusting brush can be used for hard to reach places
and at dierent heights for above oor cleaning.
MAINTAINING THE STICK VAC
Removing and retting the dirt container
1. Push down the latch on the dirt container (Fig.
11
/1 ) to release, tilt and lift to remove the dirt
container from the stick vac (Fig.
11
/2 ).
2. To ret, line up the dirt container connection
with the stick vac handle. (Fig.
12
/1) Press the
dirt container release latch (Fig.
12
/2) and push
the dirt container onto the stick vac.
WARNING: Always switch o the stick
vac and unplug from the charger and
mains before carrying out any maintenance
or troubleshooting.
!
NOTE: The powered head brushbar should
be ON for carpets and OFF for hard oors.
Constant use of the boost mode and brushbar
will reduce the battery run time.
NOTE: Before retting, if the lid of the
container with separator has been removed
for cleaning make sure the separator has been
retted and the lid has been locked into place
(Fig.
13
/1 ).
CAUTION: If the brushbar in the
powered head has been obstructed,
the brushbar motor protection sensor may
have been activated. The brushbar will stop
and the light on the powered head will
illuminate red (Fig.
18
). To reset switch
the brushbar and stick vac o, remove the
powered head from the reach wand/handheld
and clear any obstruction. Wait 1 minute
before retting the powered head tool, switch
the stick vac on and press the brushbar ON/
OFF button.
WARNING: The brushbar in the
powered head constantly rotates
when switched on. Never use the powered
head on one spot for an extended period
of time as the brushbar may damage the
oor surface. Always turn the powered head
brushbar o when cleaning hard oors. To
prevent any damage being sustained, test on
an inconspicuous area of the ooring rst.
!
