Dirt Devil BLADE 2 - Getting to Know Your Machine; Unpacking and Assembly; Attaching the Wall Mount; Charging the Stick Vac

13
GETTING TO KNOW YOUR MACHINE
Fig.
1
A. Carry handle
B. Dirt container
C. Dirt release button
D. Filter cover and lter
E. Dirt container release latch
F. Battery level indicator light
G. Boost button
H. Brushbar ON/OFF button
I. ON/OFF button
J. Charging port
K. Reach wand
L. Powered head
M. Brushbar
N. Charger
O. Wall mount, 2 screws and wall plugs
P. Crevice tool storage caddy
Contents Fig.
2
A. Crevice tool B. Dusting brush
Unpacking and assembly
1. Unpack the contents and check they are
complete. (Fig.
1
and
2
).
2. Attach the reach wand and powered head to
the handheld. They will click when locked into
place (Fig.
3
).
3. Push the crevice tool storage caddy onto the
bottom of the reach wand and slot the tool into
place (Fig.
4
).
Attaching the wall mount
1. Without the handheld attached to the reach
wand and powered head, push the wall bracket
onto the top and back of the reach wand.
(Fig.
5
/1 ).
2. Choose a location for the stick vac to be stored,
preferably near to a mains supply although not
directly above or below a mains socket. Stand the
stick vac powered head and wand against the
wall, ensuring the powered head is at on the
oor.
3. Holding the wall bracket securely against the
wall, use a pencil to make a small mark for each
screw. (Fig.
5
/2 ) Use the screws and wall plugs
to secure the wall bracket to the wall.
4. The charger cord and dusting brush can be
tted onto the wall bracket (Fig.
6
).
5. Fully assemble the stick vac and rmly press the
stick vac into the wall bracket to secure. Always
ensure the stick vac is securely locked into place.
Charging the stick vac
1. To charge the stick vac, securely attach the stick
vac into the wall bracket. You can also charge as
a handheld; detach the stick vac from the reach
wand and tools, and place on a at, stable surface.
2. Insert the charger lead into the charging port
(Fig.
1
/J ) located on the carry handle of the
handheld and plug the charger plug into the
mains.
3. The battery indicator level lights will illuminate
in turn as the battery charges, until all four lights
are illuminated (Fig.
7
/1 and
7
/2 ) Once fully
charged, the lights will go out. If charging for the
rst time the initial charge time is 4 hours.
4. When the stick vac is in use the battery level
indicator lights will illuminate indicating how
NOTE The initial charge is 4 hours and charging
will be required before rst use. Failure to
fully charge the battery before rst use may
result in poor battery performance. The life
expectancy of the battery will vary depending
on the usage of the stick vac.
EN
