6 Before every use
GB
6 Before every use
6.1 Adjusting the sensitivity of the fall sensors
1. Ensure that the appliance is switched off
(On/Off switch in the "0" position).
2. Adjust the setting of the slide controller to
the sensitivity setting of the 3 fall sensors
(Fig. 16):
- Position 0 for light floors and low steps
- Position 1 (Fig. 17) for light floors and
slightly higher steps
- Position 2 for dark floors and even high-
er steps
- Position 3 (Fig. 18) for dark floors and
high steps
1
16
3 2 1 0
3 2 1 0
17
3 2 1 0
3 2 1 0
18
WARNING:
Danger of injury! Ensure that the appliance
is switched off (On/Off switch in the "0"
position), before you mount the round
brooms.
NOTE:
All 3 slide controllers must have the same
setting.
NOTE:
If your robot moves backward continuously
on dark floors, you must select the "3" set-
ting (Fig. 18).
