EXPLODED VIEW OF X-AXIS
(F-3D)
Index
Number
Disco
Part No.
---
Description Remarks
Quantity
per Assy
1 MODTF2-6-1 --- Tape Frame
As Req’d
2A MADDXB02 --- Chuck Table Assy 3 Inch 1set
2B MADDXB03 --- Chuck Table Assy 4 Inch 1set
2C MADDXB04 --- Chuck Table Assy 5 Inch 1set
2D MADDXB05 --- Chuck Table Assy 6 Inch 1set
3 MODDXE33 --- Magnet Holder(2) 1
4 MGSK-M0305U --- Fil Hd Screw M3 x 5 8
5 MODDXC18 --- Frame Locating Pin 2
6 MOGAR219 --- Magnet 4
7A MODDXE29 --- Chuck Table 3 Inch 1
7B MODDXE30 --- Chuck Table 4 Inch 1
7C MODDXE31 --- Chuck Table 5 Inch 1
7D MODDXE32 --- Chuck Table 6 Inch 1
8 MODDXE35 --- Magnet Holder(3) 2
9 MODDXE34 --- Magnet Holder(1) 1
10 MODBNA06 --- Locating Pin 1
11 MODDN738 --- Rubber Seal 1
900830
To Next Page
