DISCO DAD 2H/6T - Main CPU Board

Index No. Part No. Description Spec. No. Mf. Q'ty
EAUA--087600 Main CPU Board MELEC 1 set
IC11 IGUPD8085AC LSI
µPD8085AC
NEC 1
IC15 - IC17, IHMBM2764-30 MEMORY IC MBM2764-30 FUJITSU 6
IC21 - IC25
IC13, IC14 IHM5M5118P MEMORY IC M5M5118P MITSUBISHI 2
IC1 IBSN74LS245N TTL IC HD74LS245P HITACHI 1
IC3
IBSN74LS00∆N
TTL IC HD74LS00P HITACHI 1
IC8, IC18
IBSN74LS08∆N
TTL IC HD74LS08P HITACHI 2
IC5
IBSN74LS14∆N
TTL IC HD74LS14P HITACHI 1
IC19
IBSN74LS32∆N
TTL IC HD74LS32P HITACHI 1
IC4, IC6, IC7 IBSN74LS138N TTL IC HD74LS138P HITACHI 3
IC20 IBSN74LS240N TTL IC HD74LS240P HITACHI 1
IC2 IBSN74LS367N TTL IC SN74LS367AN TIJ 1
IC12 IBSN74LS373N TTL IC SN74LS373N TIJ 1
IC9 IDMC14049UB MOS IC MC14049UB MOTOROLA 1
IC10 IEICL8212CPA LINEAR IC ICL8212CPA INTERSIL 1
D1 - D4 DA1S1588 Diode 1S1588 TOSHIBA 4
R6 RA1/4W0010J Carbon Film Resistor
1/4W 10ΩJ
PHILIPS 1
R2 - R4 RA1/4W1.0KJ Carbon Film Resistor
1/4W 1KΩJ
PHILIPS 3
R5 RA1/4W0047J Carbon Film Resistor
1/4W 47ΩJ
PHILIPS 1
R12 RA1/4W470KJ Carbon Film Resistor
1/4W 470KΩJ
PHILIPS 1
R10 RA1/4W200KJ Carbon Film Resistor
1/4W 200KΩJ
PHILIPS 1
R1 RA1/4W1.0MJ Carbon Film Resistor
1/4W 1MΩJ
PHILIPS 1
R11 RA1/4W1.2MK Carbon Film Resistor
1/4W 1.2MΩJ
PHILIPS 1
R13 RA1/4W4.7MK Carbon Film Resistor
1/4W 4.7MΩJ
PHILIPS 1
R8 RB1/4W15.0KF Metal Film Resistor
1/4W 15KΩF
PHILIPS 1
R7 RB1/4W56.0KF Metal Film Resistor
1/4W 56KΩF
PHILIPS 1
R9 RB1/4W0470KF Metal Film Resistor
1/4W 470KΩF
PHILIPS 1
RA1 RERA8-103-8J Resistor Network RA8-103-8J IAM 1
VR1 RHPN822H502H Potentiometer PN822H502H NEC 1
C1A, C2A CB336016-036 Tantalum Capacitor SRD33K OKI-CERA 2
C3 - C5 CD102050-047 Film Capacitor AMZ50V102K NISSEI 3
C6 CD332050-048 Film Capacitor AMZ50V332K NISSEI 1
C7 CB104035-035 Tantalum Capacitor CS15E1V0R1M1S NES 1
C1,C2 CC100050-042 Ceramic Capacitor CC45SL1H-100DY TDK 2
C8 - C33 CC103025-018 Ceramic Capacitor RSB-200-YD-103-K-5L5 NICHICON 26
X1 SCHC-18/U004 Crystal HC-18/U TOYO 1
V1 BDGB150-3FA2 Button Battery GB150-3FA2 NIHON DENCHI 1
S1 AHB-8A-T Dip Switch B-8A-T NISSHO 1
IC15 - IC17, ISYAM28-0003 IC Socket IC-99-2806 YAMAICHI 8
IC21 - IC25
CLK KKLC-1-S Check Pin LC-1-S MAC8 1
KKCRP03 Card Puller CRP03 KEL 2
FAPCB-0210 Print Board SP909-4 MELEC 1
Main CPU Board
EE0117 C-48
