DISCO DAD 2H/6T - DC Power P.C.board

Index No. Part No. Description Spec. No. Mf. Q'ty
EAUA--025100 DC Power P.C.Board 1 set
IC1 IEMC7805CT IC MC7805CT MOTOROLA 1
Q5 TB2SB434-O TR 2SB434-O TOSHIBA 1
R1 - R3 RC05W0.20K Cement Resistor
0.2Ω5W
TDO 3
R6 RC05W05.0K Cement Resistor
5Ω 5W
TDO 1
R9 RC05W0500K Cement Resistor
500Ω 5W
TDO 1
+5V, GND KKTP30 Check Terminal TP30 ROJI 4
DC10V, DC24V
C1, C2 CA109016-056 Aluminum Capacitor
ULL1C103K 10KµF 16V
NICHICON 2
C9 CA478035-179 Aluminum Capacitor
SM35T4700 4.7KµF 35V
NI-CHEMI 1
C5 CB105035-019 Tantalum Capacitor 196D-105-X9-035-H-2 NICHICON 1
C6, C10 CB334035-005 Tantalum Capacitor 150D-334-X9-035-A NICHICON 2
CJ4, CJ5 KDMOX12P223 Connector 5273-12A MOLEX 2
CJ5 KDMOX20P224 Connector 5273-20A MOLEX 1
Q1 - Q4 TEMJ2955 TR MJ2955 MOTOROLA 4
TSS2-112W-05 TR Socket S2-112W-05 3Q 4
Q1 - Q4 Mylar Sheet S-1 NEC 4
FAPCB-0076 Print Board 1
DC Power P.C.Board
C-47
