DISCO DAD 2H/6T - Y-Axis Sensor P.C. Board

Index No. Part No. Description Spec. No. Mf. Q'ty
EAUA--089800 Y-axis Sensor P.C. Board 1 set
CN1 KEJAEA08-049 P.C.B Connector IL-8P-S3FP2 JAE 1
PH1 - PH3 SBEE-SG3-B Photo Interrupter EE-SG3-B OMRON 3
R13, R23, R33 RA1/4W0470J Carbon Film Resistor
470Ω 1/4W
PHILIPS 3
R12, R15, R22, RA1/4W1.0KJ Carbon Film Resistor
1.0KΩ 1/4W
PHILIPS 6
R25, R32, R35
Q1 - 3 TC2SC1815 Transistor 2SC1815 TOSHIBA 3
C1 - 3 CD103050-008 Film Capacitor TDY-103-050-K NICHICON 3
D1 - D3 DA1S1588 Diode 1S1588 TOSHIBA 3
R11, R14, R21, RA1/4W0220J Carbon Film Resistor
220ΩJ1/4W
PHILIPS 6
R24, R31, R34
FAPCB-0179 Print Board UA0898 DISCO 1
Y-axis Sensor P.C.Board
C-32
