8
Lay the TVs in their intended position and
measure the distance between the first VESA
mount holes of each unit. This measurement
is the minimum distance between each
connector to ensure TVs will not interfere with
each other.
Measure TVs
Add Dual Connectors
Use your measurements to determine
position of 2nd connector set and attach the
additional connectors at the marked location.
NOTE: Do not place connectors
over screws on poles.
Screws
Connector
Distance between TVs
