Ditch Witch SK800 - Operator Orientation; Operating Area

SK800 Operator’s Manual Overview - 5
Operator Orientation
Operator Orientation
1. Front
2. Right side
3. Rear
4. Left side
Operating Area
Operator should stand only in the location shown.
IMPORTANT: Top view of machine is shown.
IMPORTANT: Top view of machine is shown.
t46om015w.eps
1
2
3
4
t62om004w19.eps
