SK800 Operator’s Manual Specifications - 81
SK800
Bucket width, max 44” 1120mm
Bucket width, min 36” 915mm
Dump angle, standard bucket at max dump height 35° 35°
Dump height, max, with standard bucket 66” 1676mm
Reach, standard bucket at max dump height 17” 430mm
Rear overhang, max 29” 735mm
Swing radius, max, standard bucket 65” 1650mm
Swing radius, no attachment 44” 1120mm
Operation US Metric
Ground drive speed, forward and reverse 4.3mph 6.9km/h
Ground pressure, 7” (180mm) tracks * 5.2psi 0.36bar
Ground pressure, 9” (230mm) tracks * 4.3psi 0.29bar
Machine weight (no attachment, fluids full) 2920lb 1324kg
Operating capacity (35% of tipping capacity)
The rated operating capacity for this machine was determined using a standard
bucket in the maximum reach position with center of gravity 7” (18cm) from the
attachment plate. Depending on the attachment, the actual operating capacity of
the attachment may vary.
860lb 390kg
Tipping capacity 2465lb 1118kg
* Includes machine weight, 175-lb (80-kg) bucket, 165-lb (75-kg) operator
Power Plant US Metric
Engine: Kubota® D1105, EPA Tier 4, EU Stage IIIa
Fuel Diesel
Number of cylinders 3
Displacement
68.5in
3
1.12L
Bore 3.07” 78mm
Stroke 3.09” 78.4mm
Manufacturer’s gross power rating (per SAE J1955) 24.8hp 18.5kW
Estimated net power rating (per SAE 1348) 23.1hp 17.2kW
Dimensions US Metric
