DITEC CROSS3E-73R - Limit Switches Connection for CROSS5 EH - CROSS7 EH Only (Optional)

2
CROSS3E/5EH/7EH-73R QUICK REFERENCE - IP2006
2. LIMIT SWITCHES CONNECTION FOR CROSS5EH - CROSS7EH ONLY (OPTIONAL)
Adjust the limit switch brackets!Adjust the limit switch brackets!
FCMCRFCMCR
12 011
Remove the bridges!
Connect the limit switches!
1°
2°
12 011
