CROSS3E/5EH/7EH-73R QUICK REFERENCE - IP2006
5. RADIO ENABLING
4. 73R STANDARD SETTING
i
For different setting and further information consult the CROSS3E, CROSS5EH, CROSS7EH automation instruction
manual, the 73R control panel instruction manual and BIXLR22 radio instruction manual.
DITEC S.p.A.
Via Mons. Ban, 3 - 21042 Caronno Pertusella (VA) - ITALY
Tel. +39 02 963911 - Fax +39 02 9650314
www.ditec.it - ditec@ditecva.com
6. AUTOMATIC CLOSING SETTING
-
+
TC time setting
DISABLED!
MAX
1°
-
+
TC time setting
ENABLED!
2°
MIN=0 s
MAX
120 s
MIN=0 s
MAX
120 s
VA VC TC R1
6 4
20 2
NIO
1234 5
CNO
0115689204114 13 12 11
SO
JR4
JR3
ON
OFF
DIP1 = ON
DIP2 = ON
OPENING RADIO MODE
LEFT OPENING
DIP2 = OFF
RIGHT OPENING
DIP1 = OFF
STEP BY STEP RADIO MODE
GOL4-GOL4C
Wait for 10 s
SIG
Push PRG
Led SIG comes on
Push CH
SIG
Led SIG flashes 3 times
1° 2°
SIG
NIO
PRG
JR3
