LUXO3B / 5B - E2 QUICK REFERENCE - IP2009
6. RADIO ENABLING
5. E2 STANDARD SETTING
i
For different setting and further information consult the LUXO automation instruction manual, the E2 control panel
instruction manual and BIXLR22 radio instruction manual.
SIG
PRG
ANT
GOL4-GOL4C
Wait for 10 s
SIG
Push PRG
Led SIG comes on
Push CH
SIG
Led SIG flashes 3 times
1° 2°
1
ON
OFF
234
RF
R1TR TC TM
OM
JR5
6►4
15 13 12 11 0 1 1 5689LN
UW V
XZY
SO
JR3
DIP1 = ON
OPENING RADIO MODE
DIP1 = OFF
STEP BY STEP RADIO MODE
DITEC S.p.A.
Via Mons. Ban, 3 - 21042 Caronno Pertusella (VA) - ITALY
Tel. +39 02 963911 - Fax +39 02 9650314
www.ditec.it - ditec@ditecva.com
7. AUTOMATIC CLOSING SETTING
-
+
TC time setting
DISABLED!
MAX
1°
-
+
TC time setting
ENABLED!
2°
MIN=0 s
MAX
120 s
MIN=0 s
MAX
120 s
