17
FOR FURTHER INSTALLATION ADVICE PLEASE CALL THE TECHNICAL SUPPORT HELPLINE ON 0115 900 5858.
INSTALLATION
OR
OR
OR
OR
NOTE: Once the Exhaust Hose assembly and Adjustable Window Slider are prepared, choose from one of the following
two installation methods.
1. Cut the adhesive foam seal A and
B strips to the proper lengths, and
attach them to the window sash
and frame as shown.
2. Insert the window slider assembly
into the window opening.
3. Cut the non-adhesive foam seal C
strip to match the width(or height)
of the window. Insert the seal
between the glass and the window
frame to prevent air and insects
from getting into the room.
4. If desired, install the security
bracket with 2 screws as shown.
TYPE 1: HUNG WINDOW OR SLIDING
WINDOW INSTALLATION
(FOR SOME MODELS)
PAC-H-12
To Next Page
