DIVERSITECH TYPHOON WX Series - Specifications; Diagram and Description; Technical Specifications Table; Unit Dimensions

2.2 Specifications
Model
Water
Fill
System
Nominal
Airflow
(CFM)
Tank
Capacity
(Gallons)
Motor
(H.P)
Power
Noise
@5ft.
(dB)
Phase
(hz)
@230V
(amps)
@460V
(amps)
@575V
(amps)
WX-1200 auto 1200 16 3.0 3P / 60Hz 9.6 4.8 3.9 74
WX-3000 auto 2000-3500 40 5.0 3P / 60Hz 15.2 7.6 6.1 78
WX-5000 auto 3000-5000 80 10.0 3P / 60Hz 28.0 14.0 11.0 78
WX-6500 auto 4000-6500 80 15.0 3P / 60Hz 34.0 16.9 14.0 80
1. For 1200, Airflow @ 2” external static pressure.
2. For WX-3000, WX-5000, WX-6500, Airflow @ 2.5” external static pressure.
2.3 Dimensions
4
SECTION 2 - SPECIFICATIONS
2.1 Diagram & Description
WX 1200
16 gallon, 1200 CFM
Wet Dust Collector
WX 3000
40 gallon, 3000 CFM
Wet Dust Collector
WX 5000
80 gallon, 5000 CFM
Wet Dust Collector
WX 6500
80 gallon, 6500 CFM
Wet Dust Collector
