C4 (Hi
hest Octave) = 4.000V
C3 (Hi
her Octave) = 3.000V
C2 (Middle Octave) = 2.000V
C1 (Lower Octave) = 1.000V
C0 (Lowest Octave) = 0.000V
The outputs of the sequencer are buffered, so they should maintain their voltages even when
loaded down by another module. You may find, however, that the standard calibration doesn’t
work with certain modules. In this case, you can use the trim pot to adjust the calibration so
that it is correct for your module.
