Page #74 background image
XW60K
F
VALEURS PARAMETREES PAR DEFAUT
Dégivrage Dégivrage Dégivrage
AIRE GAZ CHAUD ELECTRIQUE
Label Désignation Gamme
Par
Niveau TA
TN TB TN TB
défaut
SEt Point de consigne LS÷US -5
-
10 0 -22 0 -22
Hy Différentiel 0,1÷25,5 °C / 1÷45°F 2 Pr1 2 2 2 2 2
LS Limite basse du point de consigne
-50,0°C÷SET / -58°F÷SET
-50 Pr2 10 -5 -25 -5 -25
US Limite haute du point de consigne
SET ÷ 110°C / SET ÷ 230°F
110 Pr2 15 5 -18 5 -18
ot Calibration sonde d’ambiance -12
÷
12°C / -120
÷
120°F 0 Pr1 0 0 0 0 0
P2P Présence sonde d’évaporateur n; Y Y Pr1 n y y y y
oE Calibration sonde d’évaporateur -12
÷
12°C / -120
÷
120°F 0 Pr2 0 0 0 0 0
P3P Présence troisième sonde n; Y n Pr2 n n n n n
o3 Calibration troisième sonde -12
÷
12°C / -120
÷
120°F 0 Pr2 0 0 0 0 0
P4P Présence quatrième sonde n; Y n Pr2 n n n n n
o4 Calibration quatrième sonde -12
÷
12°C / -120
÷
120°F 0 Pr2 0 0 0 0 0
odS Temporisation activation sorties au démarrage 0÷255 min. 0 Pr2 0 0 0 0 0
AC Temporisation anti court cycle 0÷30 min. 1 Pr1 2 2 2 2 2
AC1 Temporisation activation compresseur 2 0÷255s 5 Pr2 0 0 0 0 0
rtr Pourcentage de régulation P1-P2 0 ÷ 100 (100=P1, 0=P2) 100 Pr2 100 100 100 100 100
CCt Durée cycle continu 0 ÷ 23h 50 min. 0 Pr2 0 0 0 0 0
CCS Point de consigne pour le cycle continu (-55.0÷150,0°C) -5 Pr2 -5 -5 -5 -5 -5
Con Compresseur ON en cas de défaut de sonde 0÷255 min. 15 Pr2 0 0 0 0 0
CoF Compresseur OFF en cas de défaut de sonde 0÷255 min. 30 Pr2 0 0 0 0 0
CF Unité de mesure de la température °C ÷ °F °C Pr2 c c c c c
rES Résolution (sans/avec point décimal) in ÷ de dE Pr1 in in in in in
rEd Affichage X-REP P1 ÷ 1r2 P1 Pr2 P1 P1 P1 P1 P1
dLy Temporisation affichage température 0 ÷ 20.0 min (10 sec.) 0 Pr2 0 0 0 0 0
dtr Pourcentage pour l’affichage P1-P2 1 ÷ 99 50 Pr2 50 50 50 50 50
tdF Type de dégivrage EL, in EL Pr1 EL in in EL EL
dFP Sélection sonde de fin de dégivrage nP; P1; P2; P3; P4 P2 Pr2 P2 P2 P2 P2 P2
dtE Température fin de dégivrage -50,0÷110°C / -58÷230°F 8 Pr1 20 20 20 30 30
idF Intervalle entre cycles de dégivrage 1÷120h 6 Pr1 3 3 3 3 3
MdF Durée (maximale) du dégivrage 0÷255 min. 30 Pr1 20 20 20 30 30
dSd Temporisation activation du dégivrage 0÷99 min. 0 Pr2 0 0 0 0 0
dFd Affichage pendant le dégivrage rt, it, SEt, dEF, dEG it Pr2 rt rt rt rt rt
dAd
Temporisation maximale de l’affichage après le dégivrage
0÷255 min. 30 Pr2 0 0 0 0 0
Fdt Temps de drainage 0÷60 min. 0 Pr2 0 2 2 2 2
dPo 1
er
dégivrage après le démarrage n ÷ y n Pr2 n n n n n
dAF
Temporisation dégivrage après une réfrigération rapide
0 ÷ 23h 50 min. 0 Pr2 0 0 0 0 0
FnC Mode de fonctionnement des ventilateurs C-n, C-y, O-n, O-y o-n Pr1 o-y o-n o-n o-n o-n
Fnd Temporisation ventilateurs après dégivrage 0÷255 min. 10 Pr1 3 3 3 3 3
FCt
Différentiel de temp. pour éviter des cycles courts des ventilateurs
0÷50°C 10 Pr2 0 0 0 0 0
FSt Température d’arrêt des ventilateurs
-50,0÷110°C / -58÷230°F
2 Pr1 40 40 40 40 40
Fon Durée ventilateurs ON avec compresseur off 0÷15 (min.) 0 Pr2 0 0 0 0 0
FoF Durée ventilateurs OFF avec compresseur off 0÷15 (min.) 0 Pr2 0 0 0 0 0
FAP Sélection sonde des ventilateurs nP; P1; P2; P3; P4 P2 Pr2 nP P2 P2 P2 P2
ACH Type d’action relais auxiliaire CL; Ht cL Pr2 CL CL CL CL CL
SAA Point de consigne relais auxiliaire -50,0÷110°C / -58÷230°F 0 Pr2 0 0 0 0 0
SHy Différentiel relais auxiliaire 0,1÷25,5 °C / 1÷45°F 2 Pr2 2 2 2 2 2
ArP Sélection sonde relais auxiliaire nP / P1 / P2 / P3 nP Pr2 nP nP nP nP nP
Sdd Sortie relais travaille pendant le dégivrage n, y n Pr2 n n n n n
ALP Sélection sonde alarmes de température P1÷P4 P1 Pr2 P1 P1 P1 P1 P1
ALC Configuration alarmes de température rE÷Ab rE Pr2 re re RE re RE
ALU Alarme température maximale -50,0÷110°C / -58÷230°F 10 Pr1 5 5 5 5 5
ALL Alarme température minimale -50,0÷110°C / -58÷230°F 10 Pr1 5 5 5 5 5
AFH Différentiel pour rétablissement alarme température 0,1÷25,5 °C / 1÷45°F 2 Pr2 2 2 2 2 2
ALd Temporisation alarme température 0÷255 min. 15 Pr2 15 15 15 15 15
dAo
Temporisation de l’alarme température au démarrage
0 ÷ 23h 50 min. 1,3 Pr2 3 3 4 3 4
AP2 Sélection sonde alarme condenseur nP; P1; P2; P3; P4 P4 Pr2 nP nP nP nP nP
AL2 Alarme température maximale du condensateur
(-55 ÷ 150°C) (-67÷ 302°F) -40 Pr2 -40 -40 -40 -40 -40
AU2 Alarme température minimale du condensateur
(-55 ÷ 150°C) (-67÷ 302°F) 110 Pr2 110 110 110 110 110
AH2
Différentiel pour rétablissement alarme température du condensateur
[0,1°C ÷ 25,5°C] [1°F ÷ 45°F]
5 Pr2 5 5 5 5 5
Ad2 Temporisation alarme température du condensateur 0 ÷ 254 (min.), 255=nU 15 Pr2 15 15 15 15 15
dA2
Temporisation alarme température du condensateur au démarrage
0.0 ÷ 23h 50’ 1,3 Pr2 1,3 1,3 1,3 1,3 1,3
AC2
Compresseur off pour alarme température maximale du condenseur
n(0) - y(1) n Pr2 n n n n n
bLL
Compresseur off pour alarme température minimale du condensateur
n(0) - Y(1) n Pr2 n n n n n
tbA Inhibition relais alarme n=no; y=si y Pr2 y y y y y
oA3 Configuration function sortie AUX3 ALr; dEF; Lig; AUS; Lig Pr2 Lig Lig. Lig. Lig. Lig.
onF; Fan; db; dF2
AOP Polarité sortie alarme oP; cL cL Pr2 cL cL cL cL cL
i1P Polarité entrée digitale oP; CL cL Pr1 Op Op Op Op Op
i1F Configuration entrée digitale EAL, bAL, PAL, dor; dor Pr1 dor dor dor dor dor
dEF; Htr, AUS
did Temporisation alarme entrée digitale 0÷255 min. 15 Pr1 60 60 60 60 60
nPS Nombre d’activations du switch pression 0 ÷15 15 Pr2 10 10 10 10 10
OdC
Etat des compresseurs et ventilateurs quand la porte est ouverte
no; Fan; CPr; F_C F-c Pr2 f-c f-c f-c f-c f-c
rrd Redémarrage régulation avec alarme porte ouverte n – Y y Pr2 n n n n n
HES Différentiel pour économie d’énergie -30°C÷30°C; -54°F÷54°F 0 Pr2 0 0 0 0 0
PbC Adresse série Ptc; ntc ntc Pr2 ntc ntc ntc ntc ntc
Adr Type de sonde 1÷247 1 Pr1 1 1 1 1 1
OnF Activation touche on/off nu, oFF; ES oFF Pr2 oFF oFF oFF oFF oFF
dP1 Affichage sonde d’ambiance
-
-
Pr1
-
-
-
-
-
dP2 Affichage sonde d’évaporateur
-
-
Pr1
-
-
-
-
-
dP3 Affichage troisième sonde
-
-
Pr1
-
-
-
-
-
dP4 Affichage quatrième sonde
-
-
Pr1
-
-
-
-
-
rSE Point de consigne réel
-
-
Pr1
-
-
-
-
-
rEL Version software
-
1,1 Pr2 1,1 1,1 1,1 1,1 1,1
Ptb Code de la liste des paramètres
-
-
Pr2
-
-
-
-
-
