Dixie Chopper X2002-50 - Mower Deck


', ;,( &+233(5
35=+8*+)19+):/54
)USVRKZK2OMNZ*[Z_9ZGSVKJ*KIQ
)USVRKZK.KG\_*[Z_*KIQ.
ITEM PART ITEM PART
NO. DESCRIPTION NO. NO. DESCRIPTION NO.
1. Clevis Pin
3/8
"x2-
1/4
" Long…………
…
P-103 31. Hex Bolt
5/8
"-11 x 1"………………… B-120
2. 50" Top Plate Weldment…………….. 32. "V"-Idler Pulley………………………
…
30234
3. Hairpin Cotter…………………………
…
20224 33. Bronze Bushing………………………. 30206
4. Clevis Pin
3/8
"x1-
1/2
" Long…………
…
P-102 34. Flat Idler Pulley……………………….
.
30224
5. Clevis Pin
5/16
"x1"……………………
…
P-101 35. Belt Idler Arm…………………………. 30223
6. L.H. Scissor Link Arm………………
…
30232 36.
3/8
" Flat Washer……………………… W-104
7. 50" Stamped Mower Deck Complete
…
30200-50 37. Ser. Flange Hex Nut
3/8
"-16………… N-108
50" Stamped Mower Deck Shell
…
30100 38. Bronze Bushing………………………. 20276
8. Rod End Stud………………………… S-114 (#50) 39. Shoulder Bolt
1/2
"-13 x 1-
3/4
"………. B-118-G
Nut…………………………………. N-157 40. Clevis Pin
3/8
" x 1-
1/4
"………………. P-102
Deck Lift Chain #50………………
.
68217 41. Stabilizer Bar…………………………. 30214-86
Master Link #50…………………
…
10232 42. Hex Bolt
1/2
"-13 x 1-
1/4
"……………
…
B-117
9. R.H. Scissor Link Arm………………
…
30231 43.
1/2
" Flat Washer……………………… W-109
10. 50" H.D. Mower Deck Complete.. 30200-H50 44. Long Tensioning Spring………………10222
50" H.D. Mower Deck Shell……
…
30100-H50 45. Spring Tab……………………………
…
65308
11. 50" Blow-Out Baffle (Stamped Deck
)
50315-50 46. Tower Assembly Weldment………… 67131
50" Baffle (H.D. Deck)…………… 50315-H50
12. Cam Weldment……………………….
.
30210
13. Engaging Shaft……………………….. 30211 Deck Spindle Belt (B-103)…………
…
30203
14. Hairpin Cotter…………………………
…
30213
15. Engaging Handle……………………
…
30212
16. Handle Grip……………………………
.
67258-R
17. Engaging Rod…………………………
.
68209
18. Return Spring…………………………. 20217-25
19. L Bracket……………………………… 30209-B
20. Engaging Spring……………………… 30207-S
21. Engaging Rod Assembly……………
…
30209-1
22. Hex Nut
1/4
"-20 ………………………
.
N-102
23. Hex Bolt
1/4
"-20 x
3/4
"………………
…
B-102
24. Belt Tensioning Pivot………………… 30235
25.
5/8
" Shim (4)………………………….. 30112
26. Grease Fitting………………………… F-100
27. Belt Tensioning Swing Arm…………. 30236
28.
1/2
" Lock Washer……………………. W-111-V
29. Flat Idler Pulley……………………….
.
30224
30. Hex Bolt
1/2
"-13 x
3/4
"……………….. B-115
