Item Part
No. Description No.
1.
Engine-Deck Belt
42" Deck B-80…………………………. 65080
50" Deck B-78………………………….. 30204
60" Deck B-80………………………….. 65080
2.
Deck Spindle Belt
42" Deck A-89………………………….. 63203
50" Deck B-103………………………… 30203
60" Deck B-128………………………… 30236-0
3.
Slotted Hex Nut 1"……………………….... N-142
4.
Belleville Washer 1"………………………
…
W-137
5.
Center Spindle Top Pulley
42" Deck (Steel) (All Machines)……
…
63221
50" Deck (Cast) (Stainless Machines). 30220-50V
50" Deck (Steel) (Painted Machines)
…
63221
60" Deck (Cast) (Stainless Machines). 30220-60V
60" Deck (Steel) (Painted Machines)
…
62265
6.
Washer 1"x1.5"x
1/8
"……………………….. W-131
7.
5-
1/2
" Spacer………………………………..
.
W-136
8.
All Spindle Bottom Pulley
42" Deck (Steel) (All Machines)……… 63221
50" Deck (Cast) (Stainless Machines). 30220-50
50" Deck (Steel) (Painted Machines)
…
63221
60" Deck (Cast) (Stainless Machines). 30220-60
60" Deck (Steel) (Painted Machines)
…
62265
9.
Washer 1"x1.75"x
1/4
"……………………… W-146
10.
Sealed Bearing 1"………………………….. 30218
11.
Grease Fitting………………………………. F-102
12.
Inner Deck Hub Spacer……………………. 30219
13.
Deck Hub Casting………………………….. 30241
14.
Long Blade Shaft (Center Only)…………
…
30217L
15.
Short Blade Shaft (Outboard)……………
…
30217
16.
1/2
" Blade Spacer………………………….. 30242
17.
Fiber Washer……………………………….. W-101
18.
Mower Blade
42" Deck 14"x2.5" Standard…………….. 63227-H
42" Deck 14"x3" High Lift……………
…
63227-N
50" Deck 17"x2.5" Standard……………
…
30227-H
50" Deck 17"x3" High Lift……………
…
30227-N
60" Deck 20.5"x2.5" Standard…………… 30227-60H
60" Deck 20.5"x3" High Lift…………
…
30227-60N
19.
5/8
" Belleville Washer………………………
.
W-100
20.
Blade Shaft Bolt …………………………… B-121L (Use with Blade Spacer)
Short Blade Shaft Bolt…………………….. B-121 (Use without Blade Spacer)
21.
Triangle Plate Rear "V" Idler Pulley
42",50", and 60" Decks……………….. 30234
22.
Triangle Plate Front Flat Idler Pulley
42",50", and 60" Decks……………….. 30224
23.
Deck Flat Idler Pulley
42",50", and 60" Decks……………….. 30224
24.
Transmission Pulley(not shown)………….
.
20265
25.
Transmission "V" Idler Pulley(not shown).. 30234
26.
Engine-Transmission Belt B-38 20256
