', ;,( &+233(5
-KGX(U^OYYKTZ]OZNKTJIGVY
:NKYKIGVYS[YZHKXKSU\KJGTJXKVRGIKJ
]OZN_U[XK^OYZOTM(KRR.U[YOTMY
ITEM
NO. DESCRIPTION PART NO.
1. Screw, Pan Head, Self Tap 10-24x
1/2
"………
…
792025
2. Pipe Plug, Hex Countersunk Headless
1/8
"-27 28534
3. Cover Plate……………………………………….. 772067
4. Cover Plate Gasket……………………………… 788028
5. Snap Ring………………………………………… 788018
6. Miter Gear (Downshaft)………………………… 778101
7. Downshaft Bearing………………………………. 780174
8. Downshaft……………………………………… 776360
9. Cross-Shaft (9 teeth)……………………………
…
776305
10. Miter Gear (Cross-shaft)………………………
…
778210
11. Screw, Hex Head,
1/4
"-20x
1/2
"…………………. 792026
12. Bell Housing Gasket…………………………….
.
788030
13. Cross-Shaft Bearing……………………………
…
780034
14. T-Gearbox Housing……………………………… N/A
15. Snap Ring………………………………………… 792119
16. Snap Ring………………………………………… 788019
17. Vicon Oil Seal……………………………………. 788099
18.
1/8
"MPx
3/8
"Barb Fitting…………………………. 65033
19. Hose Clamp………………………………………
.
67013
20.
3/8
" Hose…………………………………………. 65108
21. Pop-Off Valve…………………………………….. 792118
22. Fill Top Cap (Cap Only) (Optional)…………… 40117-C
23. Fill Top Cover (Cap and Lid) (Optional)………
…
68204
24. Bell Housing O-Ring……………………………
…
65024
25. Aluminum Bell Housing…………………………. 65001
:-+'8(5>9+):/54
35*+245
