PARTS LIST
ITEM PART
NO. DESCRIPTION NO.
1 Front Tire Assembly……………………………………………
…
97166
(Contains 2,3,31,32)
2 Front Rim (Rim Only)…………………………………………… 10239
Hairpin Cotter………………………………………………
…
N/A
3 Front Tire (Tire Only)…………………………………………
…
97165
4 Front Fork………………………………………………………
…
97170
5 Outer Front Wheel Spacer……………………………………
…
10203
6 Outer Front Wheel Bearing……………………………………
…
10205
7 Inner Front Wheel Bearing……………………………………
…
67205
8 Inner Front Wheel Spacer……………………………………
…
67204
9 5/8"-11 X 7" Hex Head Bolt……………………………………
…
B-122
10 5/8"-11 Hex Nut…………………………………………………
…
N-115
11 Greas e Fitting……………………………………………………
…
F-100
12 Dust Cap…………………………………………………………
…
10220
13 1" Slotted Hex Nut……………………………………………… N-142
14 Top Bearing……………………………………………………
…
10207
15 Outer Bearing Race……………………………………………
…
10206
16 Bottom Bearing…………………………………………………
…
97171
17 Seal………………………………………………………………
…
10208
18a Back Right Tire Assembly……………………………………
…
10214-RB
(Contains 19,20,33,34)
18b Back Left Tire Assembly………………………………………
…
10214-LB
(Contains 19,20,33,34)
19 Rear Rim (Rim Only
LX Models (8" x 7")……………………………………
…
61238
X, XF, XW Models (8" x 9")……………………………
…
10238
20a Rear Tire Turf Boss II (Tire Only)……………………………
…
10156-BII
20b Rear Tire CTR (Tire Only)……………………………………… 10156-C
21 Wheel Motor (14 Cu In)………………………………………
…
67114
22 Thrust Washers ………………………………………………… PB018054
23 Thrust Bearings …………………………………………………
…
PB018052
24 Dust/Shaft Seal…………………………………………………
…
PB018069
25 Snap Ring………………………………………………………
…
PB018073
26 Wheel Stud……………………………………………………… B-226
27 Wheel Flange……………………………………………………
…
N/A
Wheel Flange Assembly (Contains 26,27)………………
…
67002
28 Lug Nuts …………………………………………………………
…
N-113
29 Shaft Nut…………………………………………………………
.
PB339303P
30 Shaft Key………………………………………………………
…
PW72546
31 Brake Drum
LX Models…………………………………………………
…
97159
X, XF, XW, XXW Models…………………………………
…
67266
32
CTR Tire Assembly……………………………………………
…
10214-C
NOT SHOWN
33 Valve Stem………………………………………………………
…
10127-S
34 Tire Sealant (32 Fluid Ounce Bottle)…………………………
…
68211
