Dixie Chopper X2002-50 - Page 52


', ;,( &+233(5
ITEM PART ITEM PART
NO. DESCRIPTION NO. NO. DESCRIPTION NO.
1. Handle Grip (Black)………
…
67258 13. Lower Throttle Mounting Bracket………97011
2. Handle Weldment…………
…
97012 14. Throttle Cable (with nuts and washers) 68249
3.
5/16
" Flat Washer………… W-102 15. Hex Nut…………………………………
…
N/A
4.
5/16
"x1"Hex Head Bolt……
…
B-159 16. Washer…………………………………
…
N/A
5. Hairpin Cotter………………. 20224 17. "C" Clip…………………………………
…
C-105
6. Stainless Flat Washer,
1/4
" W-153 18. Upper StainlessThrottle Bracket………
…
65270
7.
3/8
" Flat Washer…………… W-104 19.
5/16
" Whiz Flange Nut…………………
…
N-134
8.
3/8
"-16 Nyloc Nut…………
…
N-107 20.
3/8
" Nylon Washer………………………
…
W-125
9.
3/8
" Nylon Washer…………
…
W-125 21. Stainless #10 Washer…………………
…
W-152
10. Hex Nut……………………
…
N/A 22. Stainless 10-32x
3/4
" Bolt…………………
B-203
11. Washer……………………… N/A 23
3/8
" Flat Washer………………………… W-104
12.
3/8"
Nylon Washer
……………
.
W-125 24
3/8
"x1" Hex Head Bolt…………………
…
B-108
:.85::2+'99+3(2?IUSVRKZK9+):/54
,;+2:'41
ITEM PART
NO. DESCRIPTION NO.
1. Fuel Gas Cap………
…
40117-1
2. Fuel Tank……………
…
40204-1
3. Rubber Bushin
g
……
…
40220
4.
1/4"id Fuel Line Hose
…
40211 Sold per foot
5. Hose Clamp…………. 40213
6. Gas Line Y…………
…
40230
7.
1/4
"id Fuel Line Hose
…
40211 Sold per foot
8. Hose Clamp…………
…
40213
9.
1/4
"id Fuel Line Hose.. 40211 Sold per foot
10. Hose Clamp…………. 40213
11. Tank Valve…………… 40219
12. Engine Clip………….. 45-083-01
