Set-up subject to change without notice. For packages not listed contact Dixie-Narco Factory Service at (800) 688-9090. Page 22 of 72
Package Model Loading
Depth
Cam(s)
Setting
Wide Column Shims Cam(s)
Setting
Narrow Column Shims Rear
Spacer
16.9 oz. PET Perrier Water Bottle
2.51" x 8.0"
Arrowhead, Calistoga, Ice
Mountain, Deer Park, Poland
Springs, Zephyrhills, Ozarka Logos
501E
600E
276E
2 (#3) Shim, 3/16 Flat (801,809,72x.x1)
2 per side
Shim, 3/32 Short Flat
(801,809,81x.x1)
1 per side
Extension Oscillator Paddle
w/ bottle stop (324,010,21x.x3)
1 Screw, #8-18x3/4
(900,302,02x.x1)
(#3) Shim, Can Stop (609,070,14x.x3)
1 per right side
Assy, Bottle Divider
(609,072,30x.x3) - 501E/276E
(609,072,40x.x3) - 600E
1 per column
Assy, Bottle Rod
(609,070,30x.x3) - 2 per rotor, 1
with red tube (801,903,23x.x1) in
hole A & 1 with white tube
(801,903,24x.x1) in hole C.
#18
20 oz. PET "Angle"
2.89" x 9.03"
501E
600E
276E
2 grey/red
(#3)
Shim, 3/32 Flat (801,809,81x.x1)
1 per side
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
Assy, Bottle Neck Guide
(609,072,80x.x3) - 501/276E
(610,071,30x.x3) - 600E
1 per column
Front Guide Strip
(801,810,57x.x1) - 501E/276E
(801,810,58x.x1) - 600E
1 per column
Vertical Metal Guide Clip
(800,902,40x.x1)
2 per column
#24
20 oz. PET Gatorade
2.86" x 7.76"
501E
600E
276E
2 grey/red
(#3)
Shim, 3/32 Flat (801,809,81x.x1)
1 per side
Extension Oscillator Paddle
with bottle stop (324,010,21x.x3)
1 Screw, #8-18x3/4
(900,302,02x.x1)
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
Note: Remove rear package
retainer from bottom of rotor.
Can/Bottle Chute Assy. with
extensions (615,070,60x.x3
narrow or 609,072,50x.x3 wide)
1 per vender
#15
20 oz. PET 7UP "Splash"
2.93" x 8.92"
501E
600E
276E
2 grey/red
(#3)
Shim, 3/32 Flat (801,809,81x.x1)
1 per side
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
Assy, Bottle Divider
(609,072,30x.x3) - 501E/276E
(609,072,40x.x3) - 600E
1 per column
#22
To Next Page
