SELECT PANEL TROUBLESHOOTING CHART
Problem: When vender powers up, 1-1 scrolls on the display.
Power vender down.
Check wiring to SIID.
Select harness plugged into select
panel connector.
Call Dixie-Narco
Factory Service.
Check P4 for a bent pin.
O.K.?
Check P4 for all select
switch wiring. O.K.?
Repair wiring.
Check continuity of enable lines
P4-12 and P4-13 to switches.
O.K.?
Repair ground wire.
Call Dixie-Narco
Factory Service.
Power vender back up.
Does display still show
1-1?
Retest vender and
return to service.
Yes
Yes
Yes
No
No No
No
To Next Page
