Supplements
This chapter introduces the specifications of the whole system, additional functions of the
aircraft, the operation of optional equipment, and other relevant information.
Specications
T50
Aircraft
Model 3WWDZ-40B
Weight
39.9 kg (excl. battery)
52 kg (inc. battery)
Max Takeoff Weight
[1]
Max takeoff weight for spraying: 92 kg (at sea level)
Max takeoff weight for spreading: 103 kg (at sea level)
Max Diagonal Wheelbase 2200 mm
Dimensions
2800×3085×820 mm (arms and propellers unfolded)
1590×1900×820 mm (arms unfolded and propellers folded)
1150×750×900 mm (arms and propellers folded)
Hovering Accuracy Range
(with strong GNSS signal)
D-RTK enabled: Horizontal: ±10 cm, Vertical: ±10 cm
D-RTK disabled:
Horizontal: ±60 cm, Vertical: ±30 cm (radar module enabled: ±10 cm)
Operating Frequency
[2]
2.4000-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <20 dBm (SRRC/CE/MIC), <33 dBm (FCC)
5.8 GHz: <33 dBm (SRRC/FCC), <14 dBm (CE)
RTK/GNSS Operating
Frequency
RTK: GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galileo E1/E5b, QZSS
L1/L2
GNSS: GPS L1, GLONASS F1, Galileo E1, BeiDou B1I, QZSS L1
Hovering Time
[3]
No payload for spraying: 16.5 min (takeoff weight of 52 kg with a 30Ah
battery)
Fully loaded for spraying: 7 min (takeoff weight of 92 kg with a 30Ah
battery) No payload for spreading: 15 min (takeoff weight of 53 kg with a
30Ah battery)
Fully loaded for spreading: 5.5 min (takeoff weight of 103 kg with a 30Ah
battery)
Max Configurable Flight
Radius
2000 m
Max Wind Resistance 6 m/s
Operating Temperature 0° to 45° C (32° to 113° F)
Propulsion System
Motors
Stator Size 100×33 mm
KV 48 rpm/V
Power 4000 W/rotor
