dji AGRAS T50

AGRAS T50/T25
Unmanned Aircraft Flight Manual
42
©
2023 DJI All Rights Reserved.
2
1
3
7
8
5
6
4
Nano-SIM
Mounting the Dongle and SIM Card
Dongle related functions are not supported in some countries or regions. Comply with
the local laws and regulations.
Only use a DJI-approved dongle (name: DJI Cellular Dongle (LTE USB Modem), model:
IG830).
The dongle and nano-SIM card enable the remote controller to access specific networks
and platforms such as DJI Agras Intelligent Cloud. Make sure to insert them correctly.
Otherwise, network access will not be available.
1. Press the rear cover release button to open the rear cover
1
. Remove the screws
2
and
open the dongle compartment cover
3
.
2. Insert the nano-SIM card into the dongle
4
. Insert the dongle into the USB-C connector in
the dongle compartment
5
. Close the dongle compartment cover
6
.
3. Remount the screws
7
. Close the rear cover
8
.
