dji Focus Pro - Motor Specifications

DJI Focus Pro User Manual
46
©
2024 DJI All Rights Reserved.
Motor
2.4GHz Transmitter Power
(EIRP)
< 20 dBm (CE/SRRC/MIC)
< 26 dBm (FCC)
2.4GHz Transmission
Distance
160 m*
100 m**
* Measured under FCC standard in an unobstructed environment free
of interference.
** Measured under CE/SRRC/MIC standards in an unobstructed
environment free of interference.
Mechanical Properties Dimensions: Approx. 100×61×34 mm (L×W×H)
Weight: Approx. 123 g (0.27 lbs)
Rod Diameter: 15 mm
Output Gear Teeth: 30
Output Gear Module: 0.8
Performance Max Torque: 0.6 N·m (8 V)
Max Speed: 300 rpm (8 V)
Power Supply Voltage 6.6-17.2 V
Stall Current 2 A, 8 V
Free Current 60 mA, 8 V
Operating Temperature -20° to 45° C (-4° to 113° F)
Output Voltage 6.6-17.2 V
