dji FPV Remote Controller 3 User Manual

DJI FPV
Remote Controller 3 User Manual
©
2024DJI All Rights Reserved
15
1. Turn the remote controller over and open the rubber grip on the back of the remote
controller behind the throttle stick.
2. Tighten the F1 and F2 screws ( and ) using the 1.5mm hex key included in the remote
controller package to keep the throttle stick from auto recentering.
a. Tighten the F2 screw ( ) clockwise to reduce the spring and loosen the throttle stick.
b. Tighten the F1 screw ( ) clockwise to increase the stick resistance. It is recommended to
set the stick resistance according to user preference.
3. Reattach the rubber grip once the adjustment is complete.
• Only adjust the throttle stick before the aircraft takes o. DO NOT adjust during ight.
1 2
1. F1 Right Stick Resistance Adjustment Screw (Vertical)
Tighten the screw clockwise to increase the vertical resistance of the corresponding stick.
Loosen the screw to reduce vertical resistance.
2. F2 Right Stick Spring Adjustment Screw (Vertical)
Tighten the screw clockwise to reduce the vertical spring of the corresponding stick, which in
turn will loosen the stick.
3. F1 Left Stick Resistance Adjustment Screw (Vertical)
Tighten the screw clockwise to increase the vertical resistance of the corresponding stick.
Loosen the screw to reduce vertical resistance.
4. F2 Left Stick Spring Adjustment Screw (Vertical)
Tighten the screw clockwise to reduce the vertical spring of the corresponding stick, which in
turn will loosen the stick.
• The screws that need to be adjusted vary for different control stick modes. Adjust
screw and for Mode 2. Adjust screw and for Mode 1 and Mode 3.
Adjusting the Screws
Taking Mode 2 as an example, follow the steps below to adjust F1 and F2 screws:
