[3] Master-Slave Mode Setting
[4] Video Source Setting
Single Video
DJI HD gimbal
Only DJI gimbal video signal will be
transmitted to the ground system.
Only HDMI/AV video signal will be
transmitted to the ground system.
Both DJI HD gimbal and HDMI/
AV video signals are transmitted
to the ground system. But only DJI
HD gimbal video will be displayed.
Both DJI HD gimbal and HDMI/
AV video signals are transmitted
to the ground system. But only
HDMI/AV will be displayed.
DJI HD gimbal
Dual Video Source
When single air system is paring with more than one ground system. Master-Slave
setting is required. Master ground system can display video and relay control signal to
the aircraft; slave ground system can only display video. Steps to setup: A) Tap “Master-
Slave” option in DJI Lightbridge app of the master ground system, make a note of the
master ID; B) Tap “Master-Slave” option in slave ground system, enter master ID to
connect.
Dual video source input mode is available when connecting air system to a DJI HD
gimbal. An extra video source input (HDMI / AV) can be selected as video input. Ground
system can select either of the video source to display.
Transmission distance will be reduced in Dual Video Source
mode.
HDMI/AV
HDMI/AV
Single / Dual Video
Source Setting
Video Source
Input
Remark
