dji LIGHTBRIDGE User Manual

©2014 DJI. All Rights Reserved. 47
change to master mode.
c) If linking process does not complete within 2 minutes. Redo linking. Do not place multiple
ground systems in the same area before linking proceed.
d) If the problem persist, contact DJI technical support team.
15. Q: Can I recharge ground system with battery?
A: No. Recharge ground system with DJI standard power adaptor.
16. Q: Both air and ground system indicator blink solid green. But no video display on the Android mobile
device. What should I do?
A: Follow the instruction below to resolve the issue:
a) Connect ground system to a HDMI monitor to eliminate the possible error from the ground
system.
b) Ensure Android OS version is at least 4.1.2 on the mobile device. And the “Allow USB
Debugging” option is enabled on your android device.
c) Check the version of your DJI LIGHTBRIDGE App.
d) Launch DJI LIGHTBRIDGE App, make a note on the USB connection status on the GUI. Unplug
the USB cable on the ground system. And then plug it back in. The USB connection status
should changes from “USB disconnected” to “USB connected”.
e) Should the problem persists, contact DJI technical support team.

dji LIGHTBRIDGE Specifications

General

Maximum data transfer rate	- Mbit/s
Frequency band	2.4 GHz
Interface	HDMI, AV, USB 2.0
DC-in jack	Yes
Connectivity technology	Wired
Compatible operating systems	Android 4.1.2+
