dji LIGHTBRIDGE User Manual

©2014 DJI. All Rights Reserved. 7
In the Box
Modules
Air System ×1
Ground System ×1
Air system paddle antenna ×2
Air system antenna ×3
Ground system antenna ×2
Air System Cables
GIMBAL cable ×1 (A)
If used with PHANTOM 2, connect cable to
reserved 6-PIN port on central board for air system
power supply and OSD info input.
DBUS cable ×1
Connect to flight control system DBUS port for
communication.
Air system power and CAN cable ×1
Connect to Air system GIMBAL port,
one end for power, the other for CAN port.
AV cable ×1
Connect camera’s AV output to AV input port.
HDMI cable (D-D) ×1
Connection for camera’s HDMI output.

dji LIGHTBRIDGE Specifications

General

Maximum data transfer rate	- Mbit/s
Frequency band	2.4 GHz
Interface	HDMI, AV, USB 2.0
DC-in jack	Yes
Connectivity technology	Wired
Compatible operating systems	Android 4.1.2+
