dji LIGHTBRIDGE - Page 8

©2014 DJI. All Rights Reserved. 8
Ground System Cables
Remote control cable ×1
For remote control training port connection.
Connect red port 1 to a remote control for aircraft
control and black port 2 to a remote control for
gimbal control.
Remote control training cable×1
Connect the red jack to the aircraft remote
control to control.
Training port cables（rectangle）×2
Remote control training port connection.
Charger ×1
Connect to ground system when charging.
USB upgrade cable ×1
Connect to a PC when upgrading firmware.
Optional Packet
Optional packet
(1)
HDMI cable (D-D) ×1
Ground system holder ×1
Smart phone holder ×1
Optional packet
(2)
HDMI cable for Zenmuse ×1
