dji MATRICE 200 series Quick Start Guide

8
Specifications
Aircraft (M210 V2 / M210 RTK V2)
Dimensions M210 V2: Unfolded, propellers and landing gears included, 883×886×398 mm
Folded, propellers and landing gears excluded, 722×282×242 mm
M210 RTK V2: Unfolded, propellers and landing gears included, 883×886×427 mm
Folded, propellers and landing gears excluded, 722×282×242 mm
Diagonal Wheelbase 643 mm
Max Takeoff Weight 6.14 kg
Operating Frequency 2.4000-2.4835 GHz; 5.725-5.850 GHz
Hovering Accuracy (P-mode with GPS) Vertical: ±1.64 feet (0.5 m) or ±0.33 feet (0.1 m, Downward Vision System enabled)
Horizontal: ±4.92 feet (1.5 m) or ±0.98 feet (0.3 m, Downward Vision System enabled)
Hovering Accuracy (D-RTK) Vertical: ±0.33 feet (0.1 m); Horizontal: ±0.33 feet (0.1 m)
Max Angular Velocity Pitch: 300°/s, Yaw: 150°/s
Max Pitch Angle (Dual Downward Gimbal/Single Upward Gimbal) S-mode: 30°, P-mode A-mode: 25°
Max Pitch Angle (Single Downward Gimbal) S-mode: 35°; P-mode: 30° (Forward Vision System enabled: 25°); A-mode: 30°
Max Ascent Speed 16.4 ft/s (5 m/s)
Max Descent Speed (vertical) 9.8 ft/s (3 m/s)
Max Speed (Dual Downward Gimbal/Single Upward Gimbal) S-mode: 75.6 kph (47 mph); P-mode/A-mode: 61.2 kph (38 mph)
Max Speed (Single Downward Gimbal) S-mode/A-mode: 82.8 kph (51.4 mph); P-mode: 61.2 kph (38 mph)
Max Service Ceiling Above Sea Level 9842 feet (3000 m, with 1760S propellers)
Max Wind Resistance 39.4 ft/s (12 m/s)
Max Flight Time (with TB55 batteries) M210 V2: 38 min (no payload), 24 min (takeoff weight: 6.14 kg)
M210 RTK V2: 32 min (no payload), 24 min (takeoff weight: 6.14 kg)
Supported DJI Gimbals Zenmuse X4S/X5S/X7/XT/XT2/Z30
Supported Gimbal Configurations Single Downward Gimbal, Dual Downward Gimbals, Single Upward Gimbal
Ingress Protection Rating IP43
GNSS M210 V2: GPS+GLONASS; M210 RTK V2: GPS+GLONASS+BeiDou+Galileo
Operating Temperature -4° to 122° F (-20° to 50° C)
Operating Frequency 2.4000-2.4835 GHz; 5.725-5.850 GHz
Remote Controller (GL900A)
Max Transmitting Distance
(unobstructed, free of interference)
FCC: 5 mi (8 km); CE/MIC: 3.1 mi (5 km); SRRC: 3.1 mi (5 km)
Power Supply Extended Intelligent Battery (Model: WB37-4920mAh-7.6V)
Output Power 13 W (Without supplying power to monitor)
USB Power Supply iOS: 1 A 5.2 V (max); Android: 1.5A 5.2 V (max)
CrystalSky Monitor DJI CrystalSky 7.85inch, Resolution: 2048×1536;
Brightness: 2000 cd/m
2
; Operating System: Android 5.1; Storage: ROM 64GB
Operating Temperature -4° to 122° F (-20° to 50° C)
Downward Vision System
Velocity Range <32.8 ft/s (10 m/s) at the height of 6.56 feet (2 m)
Altitude Range <32.8 feet (10 m)
Operating Range <32.8 feet (10 m)
Operating Environment Surfaces with clear patterns and adequate lighting (>15 lux)
Ultrasonic Sensor Operating Range 0.33-16.4 feet (0.1-5 m)
Ultrasonic Sensor Operating Environment Non-absorbing material, rigid surfaces (thick indoor carpeting will adversely affect performance)
Forward Vision System
Obstacle Sensing Range 2.3-98.4 feet (0.7-30 m)
FOV Horizontal: 60°; Vertical: 54°
Operating Environment Surfaces with clear patterns and adequate lighting (> 15 lux)
Upward Infrared Sensing System
Obstacle Sensing Range 0-16.4 feet (0-5 m)
FOV ±5°
Operating Environment Large, diffuse, and reflective obstacles (reflectivity >10%)
Intelligent Flight Battery (TB55-7660mAh-22.8V)
Capacity 7660 mAh
Voltage 22.8 V
Battery Type LiPo 6S
Energy 174.6 Wh
Net Weight (Single One) Approx. 885 g
Operating Temperature -4° to 122° F (-20° to 50° C)
Charging Temperature 41° to 104° F (5° to 40° C)
Max Charging Power 180 W
Charger (Model: IN2C180)
Voltage 26.1 V
Rated Power 180 W
Charging Hub (Model: IN2CH)
Input Voltage 26.1 V
Input Current 6.9 A
Download the latest version from
http://www.dji.com/matrice-200-series-v2
※ This content is subject to change without prior notice.
DJI incorporates HDMI
TM
technology.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing
LLC in the United States and other countries.
MATRICE and DJI are trademarks of DJI.
Copyright © 2018 DJI All Rights Reserved.
Printed in China.
EN

dji MATRICE 200 series Specifications

General

Max Takeoff Weight	6.14 kg
Ingress Protection Rating	IP43
Satellite Systems	GPS/GLONASS
Max Flight Time	38 minutes
Hovering Accuracy	Vertical: ±0.5 m, Horizontal: ±1.5 m
Diagonal Size	650 mm
Charging Temperature Range	5°C to 40°C
Operating Temperature Range	-4°F to 113°F (-20°C to 45°C)
