dji MATRICE 200 series Quick Start Guide

4
Using Matrice 210/Matrice 210 RTK
1. Downloading the DJI Pilot App
Users can access the DJI Pilot app that is built-in to the remote controller’s CrystalSky monitor.
Users can also search for DJI Pilot in Google Play Store or scan the QR code below to download
the app onto your mobile device, and then connect the mobile device to the remote controller.
Inter net
First-time activation requires your DJI account and an internet connection.
DJI Pilot supports Android 4.4 or later.
DJI Pilot App
2. Charging the Batteries
Press the release button and open the corresponding charging port cover.
Insert the Intelligent Flight Battery into the charging port to begin charging.
Be sure to press the release button when removing fully charged batteries.
1
A
2
Using the IN2CH Charging Hub, charging time is
approximately.
TB55: 2 hours and 33 min (two batteries)*
B
Charging Time:
2 hours and 24 min*
B
Using the WCH2 Charging Hub,
charging time is approximately 1
hour and 11 min (one battery)*
Power Outlet
100~240 V
(50Hz/60Hz)
B
A
*Provided charger
When charging is complete, the LED lights on the Intelligent Flight Battery will turn off, and the LED on the Charging Hub will turn solid green.
When charging is complete, the display on the remote controller will show 100%.
The Charging Hub will sound an alert when the battery has been fully charged. The alert can be turned on or off by toggling the switch under the hub.
Connect the Intelligent Flight Batteries to the aircraft and power them on. If battery temperature is lower than 15° C, the system will auto heat the batteries to
maintain a temperature between 15° and 20° C.
Ensure two Intelligent Flight Batteries are charged and discharged simultaneously to prolong their service life and for a better flight experience.
3. Preparing the Remote Controller
Mounting Monitor and Remote Controller Batteries
CrystalSky monitors and the Cendence S remote controller
use the same batteries.
Put the battery into the Battery Slot, then slide it to the end
until you hear a click.
Press the Battery Release Button before removing the battery.
Press the Battery Level Button once to check the battery level.
Low
High
Mounting the Monitor to the Remote Controller
A
B
Ensure that Part B is
unlocked. Connect Part
B to Part A.
Lock the Mounting
Bracket.
Use a coin or the screwdriver
included to adjust the
tightness of the tilt axis.
EN

dji MATRICE 200 series Specifications

General

Max Takeoff Weight	6.14 kg
Ingress Protection Rating	IP43
Satellite Systems	GPS/GLONASS
Max Flight Time	38 minutes
Hovering Accuracy	Vertical: ±0.5 m, Horizontal: ±1.5 m
Diagonal Size	650 mm
Charging Temperature Range	5°C to 40°C
Operating Temperature Range	-4°F to 113°F (-20°C to 45°C)
