dji MAVIC 2 ENTERPRISE Advanced Quick Start Guide

EN
5
Install the battery to the aircraft and power it on. Once the battery temperature is lower
than 6° C, it will auto heat to maintain a temperature between 8-10° C. Refer to the
User Manual for more details.
Low
High
Checking the Battery Levels and Powering On/O
Press once to check the battery level.
Press, then press and hold to turn on/off.
Press once to check the battery level on the
LCD screen.
Press once, then press and hold to turn on/
off the remote controller.
Low High
Lift the antennas Rotate to attach
the sticks
Remove the sticks
The optimal transmission range is shown above. Ensure the antennas are facing towards
the aircraft. When the angle between the antennas and the back of the Smart Controller
is 80° or 180°, the connection between the Smart Controller and the aircraft can reach
its optimal performance.
80°
3. Preparing the Remote Controller
Ensure the control sticks are rmly mounted.
In real operation, the DJI Pilot app will prompt to warn that the transmission signal
is weak, and please adjust the antennas to ensure that the aircraft is back to the
optimal transmission range.

dji MAVIC 2 ENTERPRISE Advanced Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Gray
Construction type	Ready-to-fly (RTF)
Charging time	90 min
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	5000 mAh
Cables included	AC, USB Type-C
Maximum speed	20 m/s
Frequency band	2.4 - 5.85 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum flight time	31 min
Maximum ascent speed	6 m/s
Maximum descent speed	7 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum yaw angular velocity	200 °/sec
Megapixel	48 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	2/3/5/7/10/15/20/30/60 s
Image formats supported	JPEG
Video formats supported	MP4
Maximum image resolution	8000 x 6000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	87 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	24 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Built-in processor	-

Weight and Dimensions

Depth	455 mm
Width	290 mm
Height	225 mm
Weight	1710 g
Battery weight	297 g
Transmitter weight	630 g
Takeoff weight (max)	1100 g
