dji MAVIC AIR - Battery Protection and Safety

©
2018 DJI All Rights Reserved.
31
Mavic Air User Manual
Battery Protection
The table below shows battery protection mechanisms and corresponding LED patterns.
In the event of charging temperature protection occurring the battery will resume charging once
the temperature has returned to within the allowable range. If one of the other battery protection
mechanisms activates, to resume charging once the issue has been resolved it is necessary to rst
press the Power button to turn the battery o, unplug the battery from the AC power adapter, and then
plug it back in to resume charging.
DJI does not take any responsibility for damage caused by third-party AC power adapters.
Inserting the Intelligent Flight Battery
Insert the Intelligent Flight Battery into the aircraft’s battery compartment, making sure that it is mounted
rmly and that the battery latches have clicked into place.
Removing the Intelligent Flight Battery
Slide the battery latches on the sides of the Intelligent Flight Battery and it will pop out of the battery
compartment.
Never insert or remove the battery when it is turned on.
Ensure the battery is mounted rmly. The aircraft will not take o if the battery is mounted
incorrectly.
Battery Protection Mechanisms
LED1 LED2 LED3 LED4 Blinking Pattern Battery Protection Item
LED2 blinks twice per second Overcurrent detected
LED2 blinks three times per
second
Short circuit detected
LED3 blinks twice per second Overcharge detected
LED3 blinks three times per
second
Over-voltage charger detected
LED4 blinks twice per second Charging temperature is too low
LED4 blinks three times per
second
Charging temperature is too
high
click
