Mavic Air
User Manual
5. Camera Parameters
Displays camera parameters and the capacity of the internal storage and the microSD card.
IS
HU
1600 0.31/8000
CAPACITY
1080P/2420GB
6. GPS Signal Strength
: Shows the current GPS signal strength. White bars indicate adequate GPS strength.
7. Forward and Backward Vision Systems Status
: Tap into this button to enable or disable features provided by the Forward and Backward Vision
Systems.
8. Wi-Fi Settings
2.4G
: Tap to enter the Wi-Fi Settings menu.
9. Battery Level
61%
: Shows the current battery level. Tap to view the battery information menu, set the various battery
warning thresholds, and view the battery warning history.
10. General Settings
: Tap to enter the General Settings menu to set units of measurement, enable/disable
livestream, and adjust ight route display settings.
11. Photo/Video Toggle
: Tap to switch between photo and video recording modes.
12. Gimbal Slider
: Displays the gimbal tilt angle.
13. Shoot / Record Button
/ : Tap to start shooting photos or recording video.
14. Camera Settings
: Tap to enter the Camera Settings menu.
Tap to set the camera’s ISO, shutter, and auto exposure settings.
Tap to select picture shooting modes. The Mavic Air supports Single Shot, Burst Shot,
Interval Shot, and various Panorama modes. Panorama supports four shooting sub-modes
and can capture and generate 32 megapixel sphere panorama photos.
Tap to enter the General Camera Settings menu.
15. Playback
: Tap to enter the playback page and preview photos and videos as soon as they are captured.
